HV PRO 85+(ATX3.0) 650W

  • Complies with ATX12V V3.0 &EPS12V V2.92
  • Efficiency 88% at typical load
  • Active PFC ≧ 0.9
  • Hold up time > 17ms at 80% load
  • Durable 450V / 105°C main capacitor
  • +12V Single-rail design
  • +5V &3.3V DC to DC module design
  • 120mm silent & long life sleeve fan
  • Complete protections: OCP/OVP/OPP/SCP
  • ATX 3.0
  • 80plus_Bronze230VEU
  • 62368

New ATX PSU Specifications

Updated ATX 3.0 specifications for the next-generation hardware power demands and ensure users get the most stable and cost-optimized performance possible with the highest power efficiency.
Click here to know more details.

80 PLUS® 230V Bronze - Efficiency 88%

The 80 PLUS® 230V Bronze certification indicates that a high percentage of the electricity is converted into useful power, therefore there is less heat lost and more money saved on the electricity bill.

450V 105°C, Heavy-duty capacitor

The bulk capacitor inside serves to support working under an extremely harsh environment, such as with high temperatures, peak voltage fluctuations. It stabilizes the performance for high reliability that your system can count on.

Low Noise, Less Heat

A 120mm Sleeve Fan, an advanced thermal control fan makes optimal cooling and reduces noise. And longer lifespan than a standard fan.

All Black Cables

We know what builders need. The all black cables give your system a superior look.

Stable DC to DC Output Quality

DC to DC modules with low ripple noise and prolongs system lifetime.

More Than Your Expectation

For gaming enthusiast, the HV PRO 85+ series features with dual CPU power connectors to support high-end motherboard and provide CPU stable power.


AC Input200-240Vac~  5A  50-60Hz
DC Output+3.3V+5V+12V-12V+5Vsb
Max Output Current20A20A54.1A0.3A2.5A
Max Combined Power100W649.2W3.6W12.5W
Total Power650W


 atx cable 24 pinEPS 4 4 pinpcie 6+2 pinhd statmolex2.5 floppy


Model FSP650-51AAC
Rated Output Power 650W
Form Factor ATX
80 PLUS Certification 230V EU Bronze
Input Voltage 200-240V
Input Current 5A
Input Frequency 50-60Hz
PFC Active PFC
Efficiency ≥88% at typical load
Fan Type Sleeve Bearing Fan, 120mm
Dimensions(L x W x H) 150 x 140 x 86mm
Operation Temp. 100,000 Hrs
Protection OCP, OVP, OPP, SCP
