HAMMER 600W

Hammer series (600W and 500W ) is a high CP value ATX power supply. It is featured with high efficiency ≥ 85% (at typical load, comply with 80 Plus 230V EU standard), built-in complete protection: OVP, SCP and OPP, long life 120mm silent fan and + 12V single-rail design. Its stylish black coating appearance, fully modular design and gaming sleeved cables provide PC DIY power users and gamers another optimum choice.
  • Complies with ATX12 v2.4 & EPS12 v2.92
  • Efficiency ≥ 85% @ typical load
  • Active PFC ≥ 0.9
  • Hold-up Time > 17ms
  • Fully modular design with gaming sleeved cables
  • +12V single-rail design
  • Long life 120mm silent fan
  • Complete protections: OVP, SCP, OPP

80 Plus® Certification

Hammer series meet 80 PLUS 230V EU Standard and rated for greater efficiency to 82%, so you'll enjoy lower energy bills.

Full Modular Design

Full-modular cables with all black round cables, an ideal solution for applications with space constraint issues, enhance overall airflow performance insides and provide a neat look.

Streamlined-Airflow

Optimal Cooling

Hammer series are quieter at idle, and the 120mm diameter fan reduces noise even when you're pushing your system hard.

Guaranteed of continuous power from FSP

Hammer series which include circuitry with components that can tolerate a range of 230V voltage support deliver a guaranteed watts of continuous power.

Streamlined-Airflow

Complies with the Latest CPU

Engineered according to the newest PSU guideline and compatible with the latest CPU generation.

AC/DC

AC Input200-240Vac~  5A  50-60Hz
DC Output+3.3V+5V+12V-12V+5Vsb
Max Output Current13A13A46A0.3A2A
Max Combined Power80W552W3.6W10W
Total Power600W

Cables

 atx cable 24 pinEPS 4 4 pinpcie 6+2 pinhd statmolex
ATX 20+44+4 PINPCI-E 6+2SATAMolex
(PERIPHERAL)
Connectors11253

Specifications

Model HAMMER600
Rated Output Power 600W
Form Factor ATX PSU
Input Voltage 200-240Vac
Input Current 5A
Input Frequency 60-50 Hz
PFC Active PFC ≥ 0.9
Efficiency 85% @ Typical Load
Fan Type Sleeve Fan
Dimensions(L x W x H) 150 x 140 x 86 mm
Weight 2.09 kg
Operation Temp. 100,000 Hrs.
Protection OVP, OCP, SCP
