Products
CUT592
- Support E-ATX, ATX, Micro ATX, Mini-ITX MB
- Support Dual 360mm Radiator
- Support CPU Cooler Height 175mm
- Support vertical & horizontal VGA installation
- Pre-installed 140mm x 4 ARGB fans
- High speed Type-C USB3.2 Gen2
- Easy cable management design
E-ATX Master PC Case
Ultra cooling & Ultimate expandability
Keep cool all the time
Top & front support dual 360mm radiator
140mm x 4 ARGB fan
Quieter but powerful
Bigger size, Bigger space
Support E-ATX, ATX, Micro ATX, Mini-ITX Motherboard
- Built-in VGA card holder, either vertical or horizontal
- Support maxinum 400mm VGA
- Support CPU Cooler Height 175mm
Easy-open tempered glass panel
Magnetic-open side panel, upgrade components at anytime
Easy cable management design
Built-in multiple holes for cable
Exclusive space for hard drives
Support 5 hard drives (2.5" x 3 , 3.5" x 2)
Enjoy pleasant sensation with smooth transmission
Built-in dual USB3.0 & Type-C Gen2 promote high-speed data transfers and expansion potential.
Specifications
| Model Name | CUT592 |
|---|---|
| Color | Black |
| Materials | 0.7mm SPCC, glass side panel |
| Weight | 7.9kg |
| Dimension DxWxH (mm) / (inch) | 465x230x477mm |
| Maximum CPU Cooler Height | 175mm |
| VGA Card Length | 400mm |
| Expansion Slots | 7+3 |
| MotherBoard Support | E-ATX, ATX, Micro ATX, Mini-ITX |
| External I/O port | USB3.2 Gen1 x 2 USB3.2 Gen2 Type-C HD Audio |
| Power Supply Type | ATX |
| 3.5“ HDD | 2 |
| 2.5" SSD | 3 |
| Fan Including(Pre-installed) | front：140mm ARGB x 3 rear：140mm ARGB x 1 |
| Fan&Water Cooler Support | front：140mm x 3 (pre-install) top：120mm x 3 or 140mm x 2 rear：140mm x 1 (pre-install) Bottom：120mm x 2 |
| Max Radiator Support | front：280/360mm top：280/360mm side：240mm |
| Maximum PSU Length | 200mm |
Download
CUT592 user manual.pdf
