Introduction
Building on a budget doesn’t mean you have to risk your choice to unknown brand. FSP, with years of experience in manufacturing and knowledge of PSU technology, we provide you the best solution for your home and office.
The eco-friendly design allows HEXA series to reach more than 80% efficiency, which actually exceeds the 80PLUS standard requirements at 230V/50Hz input. HEXA series also protects your PC by providing complete protection (OCP, OVP and SCP)
HEXA Series does the job efficiently and reliably, making it a stable power supply unit built to satisfy the demands on users looking for entry-level power or the budget minded system builder.

Features
- Complies with ATX 12V v2.3
- Hight efficiency >80%
- Meets 80 PLUS Certification
- Dual +12V output circuits
- 6pin PCI-Express graphic card connector ready
- Quiet, 120mm Fan
- Complete Protections: OCP, OVP and SCP
- Safety Approval: CE, CB, TUV, C-Tick, GOST
Specifications
| Model | HEXA 500 |
| Efficiency | >80% |
| Input Voltage | 200 ~ 240 Vac |
| Frequency | 50 ~ 60Hz |
| PFC | Active PFC (0.99) |
| Power Provided | 500 |
| Over-Current Protection | V |
| Over-Voltage Protection | V |
| Short-Circuit Protection | V |
| Line Type/ Main connector | 20+4 Pins |
| EPS 12V 4+4 pin Connector | 1 |
| 4 pin Floppy Connector | 1 |
| SATA Connector | 4 |
| 4 pin Molex Connector | 4 |
| PCI-E 6+2 pin Connector | 2 |
| Case Color | Black |
| Chassis Fan | 120 mm |
| Noise | >= 25dB |
| Form Factor | ATX 12V V2.3 |
| Safety Approval | CE, CB, TUV, C-tick |
| Dimensions(Lx W x H)mm | 150 x 140 x 86 |
