Products / Power Supply / RAIDER Series / RAIDER 750
RAIDER
New

RAIDER 750

Best choice in performance - RAIDER Series, 80 PLUS® Silver certified, it comes with the +12V single rail and SATA array cable design, RAIDER is made for gamers and hardware enthusiasts.
  • RAIDER PSU
  • RAIDER PSU
  • RAIDER PSU
  • RAIDER PSU
  • RAIDER PSU
  • 80Plus Silver

Introduction

Best choice in performance - RAIDER Series

The worldwide leader in high-performance power supply unit manufacturer announces RAIDER Series Power Supply. It is one of the mainstream 80 PLUS® Silver certified, efficiency > 88% and it comes with the +12V single rail, SATA array cable design, MIA IC TM and POST SR (Post Synchronous Rectification). This new series of product features exclusive full-sleeves, black PCB, also meet 2013 ErP standard (Energy Related Product).The RAIDER series' 450/550/650/750 W models are made for overclocking players, hardware enthusiasts and DIY experts!



Fully compatible with 4th generation Intel Core Series processors
FSP's power supply provide 100% Compatible with Haswell CPUs.

SATA Array Cable, Easy Installation

-50mm intervals for 4 SATA device installation

-Optimized the airflow in case

-No-hassle with case side panel



+12V Single Rail Design

-Designed for power-intensive VGA cards.

-Provides strong power to any overloading condition.





POST SR (Post Synchronous Rectifier)

Optimized the 3.3V/5V/12V start-up setting, with ZCS PFC benefits, it may avoid the switching loss and strengthen the effiency significantly.





Multiple PCI-E Connectors

PCI-E 6+2 pin connectors for all kinds of graphic cards







MIA ICTM

(Multiple Intelligence Ability) Chipset
FSP’s own patented designs to provide Ultimate Performance & Highest Protection to your system!

-Constant Hold up control performs continuous adjustments according to the output load in order to achieve the best possible efficiency;
-PFC Double-circuited Over Voltage Protection (OVP) ensures maximum protection to Capacitor;
-Zero-Current Switch on PFC ensures minimal energy wasted on switching, Low EMI and low ripple noise contribute to High Efficiency.








back to top

Features

  • +12V Single Rail Design
  • SATA Array Cable Design
  • 120mm Quite Fan
  • All Series come with PCI-E 6+2 Pin Connectors
  • FSP MIA ICTM Inside
  • 80 PLUS® Silver Certified, efficiency > 88%
  • Complies with ATX 12V 2.31 & EPS 12V 2.92 Version
  • Active PFC, power factor 99%
  • Complete Protections : OCP, OVP, OPP, SCP, UVP
  • Full Safety Approved






back to top

Specifications

Product Specification
Model RA750
Efficiency 88%
Input Voltage 100-240Vac
Frequency 50-60Hz
PFC Active PFC (0.99)
Power Provided 750W
Over-Current Protection V
Over-Voltage Protection V
Short-Circuit Protection V
Line Type/ Main connector 20+4 Pins
EPS 12V 4+4 pin Connector 1
4 pin Floppy Connector 1
SATA Connector 9
4 pin Molex Connector 3
PCI-E 6+2 pin Connector 4
Case Color black
Chassis Fan 120mm
Form Factor ATX 12V V2.31 & EPS 12V V2.92
Safety Approval CE, FCC, CB, UL/CUL, TUV, BSMI, CCC, GOST, C-tick
Dimensions(Lx W x H)mm 150 x 140 x 86
