Power Supply

PIC16100000000000122

AURUM Xilenser M 500W

  • Complies with ATX12 v2.3 & EPS12 v2.92
  • Meets 80PLUSR GOLD Certification, High efficiency > 90%
  • Dual +12V output circuits
  • Zero Noise: 0dB
  • 99% Active PFC
  • 2x 6+2pin PCI-Express graphic card connector ready
  • Industrial Grade Component: 100% Japanese capacitor
  • Complete Protections: OCP, OVP, SCP, OPP, UVP
  • Multiple Safety Approved
The world's first 500W fanless PSU "AURUM Xilenser ", Zero Noise with high efficiency. No. 1 choice for your HTPC, Lab, Studio environment. The perfect choice of your fanless power supply unit.

The only choice of the fanless power supply


AURUM Xilenser is 80PLUS GOLD certified with over 90% efficiency, continuing FSP’s unique commitment to energy efficiency with more 80PLUS certified power supplies than any other manufacturer. The high efficiency and superior passive cooling maintains a low PSU temperature – even under pressure. It is the perfect combination of premium quality and efficiency, making it the ideal choice for those who seek state of the art performance with zero noise. The completely silent and fanless operation makes it the perfect solution for your Home Theatre PC (HTPC), lab and studio environment.

(This product is only available in certain countries. Please contact your local dealer for more detail.)
100% perfect zero-noise - Absolute 0dB
FSP’s own patented designs to provide Ultimate Performance & Highest Protection to your system.
Unique Airflow Technology
Uniquely designed ventilation holes that allow natural aero dynamics to improve air extraction, keeping your PSU cooler than ever.
Low Profile Flat Cabling system-optimize airflow
1) 60cm EPS12v 8P+4P, good wiring for case
2) High extension with rich cable combination
3) Special flat cable, optimized the air flow
Active PFC
Power factor ≧99
100% Japanese-made Capacitor
Makes prolonged life span possible
Multiple Safeties & Protections Approved
let OVP/ UVP/ OCP/ SCP/ OPP protect you and your system.
Fully compatible with 4th generation Intel Core Series processors
FSP's power supply provide 100% Compatible with Haswell CPUs.

AC/DC

Model No.AU-500FL
AC Input110-240Vac ~ 6-3A 50-60Hz
DC Output+3.3V+5V+12V1+12V2-12V+5Vsb
Max Output Current20A20A22A22A0.3A2.5A
Max Combined Power100W492W16.1W
Total Power500W

Cables

 atx cable 24 pinEPS 4 4 pinpcie 6+2 pinhd statmolex2.5 floppyFan Connector
ATX 20+4 PIN4+4 PINPCI-E 6+2SATAMolex
(PERIPHERAL)
FloppyFan Connector
Connectors1145411
Model AU-500FL
Rated Output Power 500W
Form Factor ATX 12V V2.3 & EPS 12V V2.92
80 PLUS Certification Gold
Input Voltage 110-240Vac (Full Range)
Input Frequency 50-60Hz
PFC Active PFC (>0.9 typical)
Efficiency >92%
Fan Type Fanless
Noise 0 dBA
Dimensions(Lx W x H) 160 x 150 x 86mm
Operation Temp. 0~40°C / 32°F~104°F
Protection OCP/OVP/OPP/SCP/UVP
Safety Approval UL/cUL/FCC/CE/GOST/Nemko/BSMI
