HYPER K PRO ATX3.0 600W
HYPER K PRO ATX3.0 600W
- Complies with ATX12V V3.0 & EPS12V V2.92
- Efficiency ≧ 85% at typical Load
- Active PFC ≥ 0.9
- Hold up time > 17ms at 80% Load
- 120mm hydraulic bearing (HYB) fan
- 450V, 105°C capacitors for a long product life cycle
- +12V Single-rail design
- +5V &3.3V DC to DC module design
- All black round cables
- Complete protections: OCP/OVP/OPP/SCP
New ATX PSU Specifications
Updated ATX 3.0 specifications for the next-generation hardware power demands and ensure users get the most stable and cost-optimized performance possible with the highest power efficiency. Click here to know more details.
80 Plus® 230V EU Standard Certification
The HYPER K PRO series, 80 PLUS® 230V EU Standard certified, saves energy through its high efficiency up to 82% and excesses the standard through its high efficiency up to 85%.
450V 105°C, Heavy-duty Capacitor
The bulk capacitor inside serves to support working under an extremely harsh environment, such as with high temperatures, peak voltage fluctuations. It stabilizes the performance for high reliability that your system can count on.
Modern and Reliable Circuit Design
With a 12V SR circuit and the DC to DC module design, the HYPER K PRO series ensure you outstanding conversion efficiency and provides stable output voltage.
Powerful Output to Hungry VGA
+12V single rail power supply is that you will be able to feed more alternating current, specially VGA card need stable intensity to work.
The Hydraulic Bearing (HYB) Fan
It makes optimal cooling and reduces noise. And longer lifespan than a standard fan.
The HYPER K PRO series comes with 120mm fan to spin quietly and keep cooling under maximum operation.
DC-to-DC Module Design
With a 12V SR circuit and the DC to DC structure, the HYPER K PRO series ensure you outstanding conversion efficiency and provides stable output voltage.
High-end Gaming System
For gaming enthusiast, the HYPER K PRO 700W features with dual CPU power connectors to support high-end motherboard and provide CPU stable power.
Performance
AC/DC
| AC Input | 200-240Vac~ 4.5A 50-60Hz | ||||
| DC Output | +3.3V | +5V | +12V | -12V | +5Vsb |
| Max Output Current | 20A | 20A | 50A | 0.3A | 2.5A |
| Max Combined Power | 100W | 600W | 3.6W | 12.5W | |
| Total Power | 600W | ||||
Cables
 |  |  |  |  |  | |
| MB 20+4 PIN | CPU 4+4 PIN | PCIe 6+2 PIN | SATA | MOLEX | FLOOPY | |
| Connectors | 1 | 1 | 2 | 6 | 3 | 1 |
Specifications
| Model | HK-600 |
|---|---|
| Rated Output Power | 600W |
| Form Factor | ATX |
| 80 PLUS Certification | 230V EU Standard |
| Input Voltage | 200-240V |
| Input Current | 4.5A |
| Input Frequency | 50-60Hz |
| PFC | Active PFC |
| Efficiency | ≥85% at typical load |
| Fan Type | Hydraulic Bearing (HYB) Fan,120mm |
| Dimensions(L x W x H) | 150 x 140 x 86mm |
| Weight | 1.615 kgs |
| Protection | OCP, OVP, OPP, SCP |
Download
UserManual_PSU.pdf
